euroBLADE

WALL AND CEILING BLADES

If modern lines are the effect you need for your design, then euroBLADE may be the answer. the use of natural timber, polyurethane or prefinished laminate colour will certainly add the desired architectural element to your space.

Downloads

Installation Information

EUROBLADE TO WALLS VERTICAL BATTEN DIRECTION

Your Title Goes Here
Direct Fixing (suggested method)
Panels with horizontal matt black substrates are direct fixed to installed horizontal wall battens.

Plan section showing split batten fixing

Split Batten Fixing

Panels with horizontal substrates are installed using split battens fixed to the back of the panel, interlocking with split battens fixed to vertical wall battens.

Plan section showing split batten fixing

EUROBLADE TO WALLS HORIZONTAL BATTEN DIRECTION

Your Title Goes Here
Direct Fixing (suggested method)

Panels with vertical matt black substrates are direct fixed to installed horizontal wall battens.

Plan section showing split batten fixing
Black screws are used so that the black coloured screw head is hidden in the spacing between the battens.

Split Batten Fixing

Panels wtih small split batten blocks fixed to matt black substrates are installed to split battens fixed to vertical wall battens.

Plan section showing split batten fixing

EUROBLADE S1, S2, S3 TO CEILINGS

Your Title Goes Here

Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.

Direct Screw Fix to Grid – from above

Panels are secured from above the grid, by screwing down through the furring channel into the back of the substrate crossmembers.

Plan section showing direct screw fix to grid – from above

Direct Screw Fix to Grid – from below

Panels are secured by fixing from the underside, through the matt black substrate into the furring channel using black screws hidden in the spaces between the battens.

Plan section showing direct screw fix to grid – from below

Accoustic Datasheets

europanel have invested heavily in commissioning a large amount of testing at Melbourne’s RMIT University’s ‘Acoustically Isolated Reverberation Chamber’, and achieved certification data in accordance with Australian Standard ISO 354-2006.

Your Title Goes Here
euroBLADE S1

euroBLADE S1/50/GW | NRC 0.80

euroBLADE S1/400/GW | NRC 1.00

euroBLADE S1 custom/400/PO (type 1) | NRC 0.85

euroBLADE S1 custom/400/PO (type 2) | NRC 0.85

euroBLADE S2

euroBLADE S2/50/GW | NRC 0.55

euroBLADE S2/400/GW | NRC 0.65

euroBLADE S3

euroBLADE S3/50/GW | NRC 0.65

euroBLADE S3/400/GW | NRC 0.85



Design Flexibility

Design the euroBLADE to suit your space with custom blade size, spacing and finish. Our design team will work with you throughout the design process to finalise an approved design and provide a custom number to ensure easy specification.

Finishes

euroBLADE is available in natural timber finishes, or if a uniform colour better suits the aesthetics of your design, a polyurethane or prefinished cover can be applied in any colour or finish.

With Australians often looking to make greener living choices, architects, specifiers, engineers and home owners are increasingly choosing Western Red Cedar as sustainable building material.

Also along with its natural ‘lightweight’ characteristics, Western Red Cedar has a zero carbon footprint.

For our standard euroBLADE panels we utilise Western Red Cedar for these qualities, however any species of timber can be easily used if a specific grain or colour texture is to be achieved.

Accoustic Backing

euroBLADE offers the option to include a thin fireproof soundmesh acoustic lining fabric. This material is purposely designed to replace traditional bulky materials and has been engineered to maximise sound absorption to add more acoustic value to your space. Refer to our acoustics page or more.

Substrate

Standard euroBLADE is constructed using 25mm painted ‘matt black’ crossmembers, with either solid timber or polyurethane finished MDF batten strips.

Fixing

Ceiling Blades: ceiling blades are fixed to a furring channel grid system.
Wall Blades: Wall blades can be fixed either onto a structural wall, or using split batten system to become removable.

Design Flexibility

Design the euroBLADE to suit your space with custom blade size, spacing and finish. Our design team will work with you throughout the design process to finalise an approved design and provide a custom number to ensure easy specification.

Finishes

euroBLADE is available in natural timber finishes, or if a uniform colour better suits the aesthetics of your design, a polyurethane or prefinished cover can be applied in any colour or finish.

With Australians often looking to make greener living choices, architects, specifiers, engineers and home owners are increasingly choosing Western Red Cedar as sustainable building material.

Also along with its natural ‘lightweight’ characteristics, Western Red Cedar has a zero carbon footprint.

For our standard euroBLADE panels we utilise Western Red Cedar for these qualities, however any species of timber can be easily used if a specific grain or colour texture is to be achieved.

Accoustic Backing

euroBLADE offers the option to include a thin fireproof soundmesh acoustic lining fabric. This material is purposely designed to replace traditional bulky materials and has been engineered to maximise sound absorption to add more acoustic value to your space. Refer to our acoustics page or more.

Substrate

Standard euroBLADE is constructed using 25mm painted ‘matt black’ crossmembers, with either solid timber or polyurethane finished MDF batten strips.

Fixing

Ceiling Blades: ceiling blades are fixed to a furring channel grid system.

Wall Blades: Wall blades can be fixed either onto a structural wall, or using split batten system to become removable.

Download euroBlade fixing guide

Standard Blade Designs

Choose from a three standard blade designs or create your own, Sample blades are available in any design and finish to assist with the design and approval process. Click thumbnails below to download a specification PDF.



How to specify euroBLADE

EXAMPLE SPECIFICATION: EB–S1–T–WESTERN RED CEDAR

ProducteuroBLADEEB
DesignStandard CustomS#
C#
State number
State custom number
Finish

Timber
Prefinished
Polyurethane

PR
Other

Species/colour

?

State species/colour
